Parameters

• Model

  BT STICK 400 CEL

  BT STICK 500 CEL

• Power supply voltage(V)

  3~400

  3~400

• Power frequency (Hz)

  50/60

  50/60

• MMA

  TIG

  MMA

  TIG

• Effective current (A)

  24.8

  18.6

  32.5

  25.8

• Rated input current (A)

  32

  24

  42

  33.4

• Rated Input Power (KW)

  22.1

  16.6

  29.1

  23.2

• Duty Cycle(40℃ 10Min)

  60% 400A 100% 310A

  60% 500A 100% 385A

• Welding Current Range(A)

  20-400

  20-500

• No Load Voltage(V)

  93.5

  96

  91.5

• Efficiency (%)

  89.2

  89.8

• Power factor

  0.75

  0.72

  0.77

  0.75

• Insulation Class

  F

  F

• Protection Class

  IP21S

  IP21S

• Cooling

  AF

  AF

• Net Weight(Kg)

  28.1

  30.7

• Dimensions(mm)

  700*265*490

  700*265*490
