Parameters

• power supply voltage(V)

  3~400

• Power frequency(HZ)

  50/60

• TIG

  MMA

• Effective current (A)

  10.2

  14.2

• Rated input current (A)

  13.2

  18.4

• Rated Input Power (KW)

  9.2

  12.8

• Duty Cycle(40℃ 10Min)

  60% 250A 100% 195A

• Welding Current Range(A)

  10-250

  10-250

• No Load Voltage(V)

  76

  73

• Efficiency (%)

  85.6

• power factor

  0.66

  0.68

• Insulation Class

  F

• Protection Class

  IP21S

• Cooling

  AF

• Net Weight(Kg)

  12.8

• Dimensions(mm)

  550*190*360
